Feature;  Value

Shipping date View

Mounting type On solenoid valve with M2.5 central screw

Assembly position Any

Product weight 125 g

Electrical connection Plug socket angled

Per DIN EN 175301-803

Plug pattern type C to EN 175301-803

3-pin

Nominal operating voltage, AC 230 V

Protective earth connection Available

Cable length 2.5 m

Cable diameter 5.2 mm

Cable structure 3x0,5

Protection class IP65

to IEC 60529

Ambient temperature -20 ... 80 °C

CE mark (see declaration of conformity) to EU directive low-voltage devices

Corrosion resistance classification CRC 1 - Low corrosion stress

Material cable sheath PVC

Material housing PA66-GF30

Material electrical contact Bronze
