- Rated operational current: 37-1000A

- Parameterizable overload settings: 31-100%

- Adjustable overload classes: class 5,10,20,30

- Base setting: 15s start ramp, 4 starts per hour, 300% starting current at 40oC ambient temperature

- Allocated motor outputs for in-line connection:

• 7.5 - 277 kW (3~ 230V)
• 18.5 - 525 kW (3 ~ 400V)
• 30 - 900 kW (3 ~ 690V)

- 5 compact designs

- Adjustable torque control

- Adjustable kick start

- 24-V control voltage:

• External supply required
• 1 A continuous current
• 10A starting current (peak value for 15ms)
