Wall-mounted cooling units TopTherm

Wall-mounted cooling units TopTherm "Blue e" Total cooling output 0.50 – 0.75 kW / 3303500 / Rittal /

Giá: Liên hệ

Tên sản phẩm: Cooling units

Nhãn: rittal

Mã sản phẩm:  3303500

Wall-mounted cooling units TopTherm "Blue e" Total cooling output 0.50 – 0.75 kW / 3303500 / Rittal /

RITTAL / 3303500 /

/MVN/

Số lượng
  • Thông tin sản phẩm
  • Yêu cầu gửi báo giá
  • Total cooling output to DIN EN 14511 L 35 L 35 at 50 Hz: 0.55 kW (1876 BTU)
    L 35 L 35 at 60 Hz: 0.66 kW (2252 BTU)
    L 35 L 50 at 50 Hz: 0.33 kW (1126 BTU)
    L 35 L 50 at 60 Hz: 0.4 kW (1364 BTU)
    Rated operating voltage 230V 1~ 50Hz/60Hz
    Rated current (max) At 50 Hz: 2.6 A
    Material Carbon steel
    Temperature range Ambient temperature range: +10°C...+55°C
    Setting range: +20°C...+55°C
    Dimensions Height: 550 mm (22 ")
    Width: 280 mm (11 ")
    Depth: 210 mm (8.3 ")
    Color RAL 7035
    Protection category IP to IEC 60 529 Internal circuit IP 54
    External circuit IP 34
    Rated Power Pel L 35 L 35 at 50 Hz: 0.39 kW
    L 35 L 35 at 60 Hz: 0.41 kW
    L 35 L 50 at 50 Hz: 0.45 kW
    L 35 L 50 at 60 Hz: 0.42 kW
    Energy efficiency ratio (EER) 50 Hz L35 L35 to DIN EN 14511 1.4
    Temperature control e-Comfort Controller (factory setting +35°C)
    Weight/packaging unit 17 kg (37.5 lb.)
    Refrigerant-cooling medium Refrigerant: R134a
    Quantity: 170 g (6 oz)
    Global Warming Potential (GWP): 1430
    CO₂ equivalent (CO₂e): 0.24 t
    Supply includes Drilling template
    Fasteners
    Nano-coated condenser
    Wired ready for connection (plug-in terminal strip)
    Note The technical specifications for the wall-mounted cooling unit 3361.540 are valid with an external transformer connected.
    Packaging unit 1 pc(s).
