| Shipping date |
 View |
| Size |
6 |
| Series |
MSE |
| Assembly position |
Horizontal +/- 5° |
| Valve function |
2/2 open, monostable |
| Operating pressure |
5 ... 11 bar |
| Authorisation |
RCM Mark |
| KC mark |
KC-EMV |
| CE mark (see declaration of conformity) |
to EU directive for EMC |
| Operating medium |
Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation not possible |
| Corrosion resistance classification CRC |
2 - Moderate corrosion stress |
| Storage temperature |
-10 ... 60 °C |
| Medium temperature |
0 ... 50 °C |
| Protection class |
IP65
with plug socket |
| Ambient temperature |
0 ... 50 °C |
| Product weight |
4,550 g |
| Pneumatic connection, port 1 |
G1/2 |
| Pneumatic connection, port 2 |
G1/2 |
| Material seals |
NBR |
| Material housing |
Aluminium die cast |
| Material of cover |
PA-reinforced |
| Material cover |
PA-reinforced |
| Fieldbus interface |
2x RJ45 push-pull socket, AIDA |
| Operating voltage range, DC electronics/sensors |
18 ... 30 V |
| DC operating voltage, load voltage |
21.6 ... 28.8 V |
| Polarity protected |
For operating voltage connections |
| Unit(s) that can be displayed |
kPa
l
l/min
m3
mbar
psi
scf
scfm |
| Flow measurement range initial value |
50 l/min |
| Flow measurement range final value |
5,000 l/min |
| Accuracy of flow rate |
± (3% o.m.v. + 0,3% FS) |
| Pressure measuring range, initial value |
0 bar |
| Pressure measuring range, final value |
14 bar |
| Accuracy, FS |
3 %FS |
| No. of inputs |
2 |
| Input circuit logic |
PNP (positive-switching) |
| No. of outputs |
2 |
| Switching logic, outputs |
PNP (positive-switching) |
| Max. power supply per channel |
1 A (12 W lamp load)A |
