Interruption plug - FIP-3/3 SERVICE - 3069312 - PHOENIX CONTACT
Tên sản phẩm: Interruption plug
Nhãn: Phoenix contact
Mã sản phẩm: 3069312 // 1 số mã sản phẩm tương đương
| 3069921
|
Interruption plug - FIP-3/1 SERVICE |
| 3069920 | Interruption plug - FIP-3/2 SERVICE |
| 3069312 | Interruption plug - FIP-3/3 SERVICE |
| 3069313 | Interruption plug - FIP-3/4 SERVICE |
Interruption plug - FIP-3/3 SERVICE - 3069312 - PHOENIX CONTACT
Thông tin chi tiết sản phẩm
Country of origin PL (Poland)
General
Number of positions 3
Color red
Insulating material PA
Flammability rating according to UL 94 V0
Rated surge voltage 4 kV
Test surge voltage 5 kV
Ambient temperature (operation) -60 °C ... 85 °C
Ambient temperature (storage/transport) -25 °C ... 55 °C (For a short time, not exceeding 24 h, -60 to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C
Dimensions
Width 24.5 mm
Length 53.4 mm
Pitch 8.2 mm
