TRIO-BAT/PB/24DC/4AH - Battery module 1394730
TRIO-BAT/PB/24DC/4AH - Battery module 1394730
UPS Battery module, VRLA-AGM, 24 V DC, 4 Ah, with lead AGM (Absorbent Glass Mat) technology, batteries are fully charged before being despatche
Phoenix Ethernet Series: Trio UPS Battery Module
Input Voltage: 24 V DC
Operating Voltage: DC 24 V
Output Type: 4 Ah
Catalogue sản phẩm: Phoenix Contact Catalogue
Thông tin chi tiết sản phẩm
- Input Data
Input voltage: 24 V DC (SELV)
Nominal capacity: 4 Ah
Charging current max:. 1.2 A
End-of-charge voltage: 27.6 V (20 °C)
- Output Data
Output current max: 25 A
1x 25 A T 25A 32V, ATOF 287 from Littelfuse
Buffer time: 4.5 min. (20A), 3 min. (25 A)
End-of-discharge voltage: 19.2 V
