| Nominal size, Laval nozzle |
0.45 ... 0.95 mm |
| Grid dimension |
10 ... 15 mm |
| Design, silencer |
open |
| No. of device positions |
2 ... 8 mm |
| Assembly position |
Any |
| Ejector characteristic |
High suction flow rate
High vacuum
Standard |
| Grade of filtration |
40 µm |
| Manual override |
Pushing |
| Integrated function |
Ejector pulse, electrical
Flow control valve
Pressure sensor
Pressure transmitter
Electrical on-off valve
Filter
Open silencer |
| Design structure |
Connection position on both sides
Connection position on the side |
| Switching element function |
Normally closed contact
Normally open contact
Switchable |
| Switching function |
Freely programmable |
| Valve function |
closed |
| Measurement method |
Piezoresistive pressure sensor
Piezoresistive pressure sensor with display |
| Type of display |
LED display
2-digit |
| Setting options |
IO-Link
Teach-In
Via display and buttons |
| Operating pressure for max. suction rate |
3 ... 6 bar |
| Operating pressure |
2 ... 7 bar |
| Operating pressure for max. vacuum |
3.8 ... 4.5 bar |
| Max. vacuum |
89 ... 92 % |
| Nominal operating pressure |
4 bar |
| Max. suction rate with respect to atmosphere |
4 ... 45 l/min |
| Air supply time at nominal operating pressure |
0.4 ... 2 s |
| Analogue output |
0 - 10 V
1 - 5 V |
| Operating voltage range DC |
21.6 ... 26.4 V |
| Duty cycle |
100 % |
| Switch output |
PNP/NPN, switchable |
| Characteristic coil data |
24 V DC: 1 W |
| CE mark (see declaration of conformity) |
to EU directive for EMC |
| Operating medium |
Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation not possible |
| Corrosion resistance classification CRC |
2 - Moderate corrosion stress |
| Medium temperature |
0 ... 50 °C |
| Noise level at nominal operating pressure |
52 ... 68 dB(A) |
| Protection class |
IP40 |
| Ambient temperature |
0 ... 50 °C |
| Product weight |
118 ... 890 g |
| Operating voltage range, DC sensor |
10 ... 30 V |
| Pressure measuring range |
-1 ... 0 bar |
| Electrical connection, input, function |
Ejector pulse
Vacuum generation |
| Electrical connection, input, connection type |
2x plug |
| Electrical connection, input, connection technology |
Connection pattern H |
| Electrical connection, input, number of pins/wires |
2 |
| Electrical connection, input, type of mounting |
Snap-in locking |
| Electrical connection, output, function |
Sensor |
| Electrical connection, output, connection type |
Cable |
| Electrical connection, output, connection technology |
Open end |
| Electrical connection, output, number of pins/wires |
3 |
| Cable attribute |
Suitable for chain link trunking |
| Cable diameter |
2.9 mm |
| Cable diameter tolerance |
± 0,1 mm |
| Cable length |
2.5 m |
| Nominal conductor cross-section |
0.14 mm2 |
| Mounting type |
with through hole |
| Pneumatic connection, port 1 |
Female thread G1/8
For tubing outside diameter 6 mm
For tubing outside diameter 8 mm |
| Pneumatic connection, port 3 |
Open silencer
For tubing outside diameter 4 mm
For tubing outside diameter 6 mm |
| Vacuum connection |
For tubing outside diameter 3 mm
For tubing outside diameter 4 mm
For tubing outside diameter 6 mm |
| Cable sheath colour |
Grey |
| Material of connecting thread |
POM |
| Materials note |
Conforms to RoHS |
| Material of connecting plate |
Wrought Aluminium alloy |
| Material seals |
NBR |
| Material receiver nozzle |
POM |
| Material filter |
POM |
