- Input:
| Measurement | |
| Configurable/programmable | Yes |
| Input voltage range | 0 V AC ... 550 V AC |
| Input resistance of voltage input | 5500 kΩ |
| Maximum input voltage | + 660 V AC |
| Impulse form | AC voltage |
| Measurement | |
| Input voltage range | 0 V AC ... 370 V AC |
| Input resistance of voltage input | 3700 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 250 V AC |
| Input resistance of voltage input | 2500 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 170 V AC |
| Input resistance of voltage input | 1700 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 120 V AC |
| Input resistance of voltage input | 1200 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 80 V AC |
| Input resistance of voltage input | 800 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 54 V AC |
| Input resistance of voltage input | 800 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 36 V AC |
| Input resistance of voltage input | 800 kΩ |
| Measurement | |
| Input voltage range | 0 V AC ... 24 V AC |
| Input resistance of voltage input | 240 kΩ |
- Output:
| Signal: Voltage | |
| Voltage output signal | 0 V ... 10 V |
| 2 V ... 10 V | |
| Max. voltage output signal | ≤ 11 V |
| Load/output load voltage output | > 10 kΩ |
| Ripple | 50 mV |
| Signal: Current | |
| Current output signal | 0 mA ... 20 mA |
| 4 mA ... 20 mA | |
| Max. current output signal | ≤ 22 mA |
| Load/output load current output | < 500 Ω |
| Max. capacitive load | < 1000 pF |
| Max. inductive load | < 1 mH |
