Xuất xứ: Đức
Product definition
Application AC charging controller for private and commercial applications (EU/CN)
Standards/regulations IEC 61851-1
Charging mode Mode 3, Case B + C
Dimensions
Height 90 mm
Width 162 mm
Depth 61.00 mm
Device supply
Supply voltage 230 V
Supply voltage range 100 V AC ... 240 V AC (nominal voltage range)
Nominal power consumption < 3 W (No-load)
Power consumption < 10 W (maximum)
Frequency range 50 Hz ... 60 Hz
Switching outputs
Control of charging contactor Relay output C1.2
Minimum switching capacity 4000 VA
Maximum switching voltage 250 V AC (External supply)
Max. switching current 16 A
Control of locking actuator Motor switching output
Maximum switching voltage 12 V (Internal supply)
Inputs
Number of digital inputs 5
Description of the input Digital input
Nominal current IN ≤ 4 mA
Nominal input voltage UN 12 V
Input voltage range U1 0 V ... 3 V (Off)
Input voltage range U2 9 V ... 15 V (On)
