Country of origin GB (United Kingdom)
Dimensions
Length 41 mm
Thread pitch 1.5 mm
Wrench size, union nut 36 mm
Wrench size, support 36 mm
Hexagon angular dimension 39.6 mm
Length of the connecting thread 15 mm
External cable diameter 11.1 mm ... 20 mm
Cable types that can be used for unarmored cables
Ambient conditions
Degree of protection (IP) IP66 (using the corresponding A-SEW-...P-W flat gasket)
IP67 (using the corresponding A-SEW-...P-W flat gasket)
IP68 (using the corresponding A-SEW-...P-W flat gasket)
Ambient temperature (operation) -60 °C ... 130 °C (static)
General
Cable gland material Nickel-plated brass
Cable seal material EPDM
Thread type connection side M25 x 1.5
Color silver
Impact energy 20.00 J
Assembly instructions Sealed to IP66/IP67/IP68 thanks to the use of the A-SEW-25-P-W flat gasket (item 1411284)
Standards/specifications EN 60079-0, -1, -7, -15, -31
IEC 60079-0, -1, -7, -15, -31
EN 50262
BS 6121: Part 1:1989
IEC 62444
Manufacturer CMP
Manufacturer product number 25A2F1RA5
Manufacturer Designation 25 A2F N. PLTD GLAND
Suited for EX-applications yes
