- Measuring principleMagnetic reed
- Ambient temperature-40 °C ... 70 °C
- Switching outputContact-based, bipolar
- Switching element functionN/O contact
- Max. output current80 mA
- Max. output current in mounting kits80 mA
- Min. switching capacity AC2.4 VA
- Max. switching capacity DC2.4 W
- Max. switching capacity DC in mounting kits2.4 W
- Max. switching capacity AC in mounting kits2.4 VA
- Voltage drop4.8 V
- Short-circuit protectionno
- Overload protectionNot available
- Operating voltage range AC5 V ... 30 V
- DC operating voltage range5 V ... 30 V
- Reverse polarity protectionno
- Electrical connection 1, connection typeCable
- Electrical connection 1, connection technologyOpen end
- Electrical connection 1, number of pins/wires2
- Connection outlet orientationLongitudinal
- Connector cable test conditionsFlexural strength: as per Festo standard Test conditions on request Energy chain > 5 million cycles, bending radius 75 mm
- Cable length2.5 m
