Country of origin HU (Hungary)
Ambient conditions
Ambient temperature (operation) -40 °C ... 70 °C (fixed installation)
-10 °C ... 70 °C (flexible installation)
Ambient temperature (storage/transport) -40 °C ... 80 °C
Maximum altitude ≤ 2000 m
Degree of protection IP20
≥ IP54 (Installation location)
General
Max. permissible operating voltage 25 V AC
60 V DC
Max. current carrying capacity per path 2 A (see to derating)
Length of cable 6 m
External cable diameter 7.9 mm ±0.5 mm
Single wire, cross section 0.25 mm²
Single wire, cross section [AWG] 24
Single wire, number of litz wires 14
Single wire, material Cu uninsulated
Wire diameter incl. insulation 1.2 mm ±0.05 mm
Smallest bending radius, fixed installation 67 mm
Connection data
Connection name Field level
Connection method D-SUB pin strip
Number of connections 1
Number of positions 15
Torque 0.2 Nm
Insertion/withdrawal cycles > 200
