Country of origin DE (Germany)
Dimensions
Height 105.8 mm
Width 6.2 mm
Depth 55.6 mm (incl. DIN rail 7.5 mm)
Ambient conditions
Ambient temperature (operation) -30 °C ... 60 °C
Ambient temperature (storage/transport) -40 °C ... 70 °C
Humidity test 96 h, 95 % RH, 40 °C
Altitude ≤ 3000 m up to 52 °C (amsl (above mean sea level))
≤ 4000 m up to 46 °C (amsl (above mean sea level))
Shock (operation) 30g (IEC 60068-2-27, Test Ea)
General
Flammability rating according to UL 94 V-0
Mounting type DIN rail: 35 mm
Color traffic grey A RAL 7042
Number of positions 1
Protection class III
Degree of pollution 2
Type DIN rail module, one-piece
Electrical data
Fuse type electronic
Rated surge voltage 0.5 kV
Operating voltage 18 V DC ... 30 V DC
Rated voltage 24 V DC
Rated current IN 24 A DC (Total current input)
8 A DC (Rated current output)
