Country of origin DE (Germany)
Dimensions
Width 6.2 mm
Height 80 mm
Depth 86 mm
Ambient conditions
Ambient temperature (operation) -20 °C ... 50 °C
Ambient temperature (storage/transport) -20 °C ... 70 °C
Degree of protection IP20
Supply
Rated control circuit supply voltage US 24 V DC
Rated control supply voltage range with reference to US 0.8 ... 1.1
Rated control supply current IS 13 mA
Type of protection Reverse polarity protection
Surge protection
Operating voltage display Green LED
Indication Red LED
Input data
Input name Analog current input
Current input signal 0 mA ... 20 mA
4 mA ... 20 mA
Input resistance current input ~ 40 Ω
Maximum temperature coefficient 0.01 %/K
Maximum transmission error 1 %
Surge voltage protection > 33 V
Input name Analog voltage input
Voltage input signal 0 V ... 10 V
2 V ... 10 V
Input resistance of voltage input > 120 kΩ
Maximum temperature coefficient 0.01 %/K
Maximum transmission error 1 %
Surge voltage protection > 33 V
Output data
Output name Digital output
Connection data
Connection method Screw connection
Stripping length 8 mm
Screw thread M3
Number of connections 4
