Dimensions
Outer dimensions: width, height, depth (dependent on configuration)
Installation dimensions: width, height, depth 394.4 mm x 263.2 mm (Panel cutout for 15.6-in. display)
455 mm x 303.2 mm (Panel cutout for 18.5-in. display)
522 mm x 344 mm (Panel cutout for 21.5-in. display)
Back to top
Display
Display type 39.6 cm/15.6" TFT
47.0 cm / 18.5" TFT
54.6 cm/21.5" TFT
Screen resolution 1366 x 768 Pixel(s) (WXGA), 15.6" TFT; 18.5" TFT
1920 x 1080 Pixel(s) (Full HD)
Touch technology projective-capacitive, ten-touch control
Brightness 300 cd/m², typical (adjustable)
Backlighting LED
Display backlight MTBF > 50000 h (Dependent on configuration)
Colors 16.7 million colors
Ambient conditions
Degree of protection IP66 (front), IP30 (back)
IP65 (Front)
IP30 (back)
Ambient temperature (operation) 0 °C ... 45 °C (with HDD)
-20 °C ... 50 °C (with SSD)
Ambient temperature (storage/transport) -40 °C ... 70 °C
Permissible humidity (operation) 5 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 5 % ... 95 % (non-condensing)
Vibration (operation) 1g with SSD, 0.5g with HDD, according to EN 60068-2-6
Shock DIN EN 60068-2-27
