Country of origin DE (Germany)
Width 45 mm
Height 130 mm
Depth 126 mm
Ambient conditions
Ambient temperature (operation) -40 °C ... 70 °C (Maximum transmission power 5 dBm)
-40 °C ... 60 °C (Maximum transmission power 23 dBm)
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Altitude ≤ 5000 m (For restrictions, see the manufacturer's declaration for altitude operation)
Degree of protection IP20
Noise immunity EN 61000-6-2
General
Electrical isolation VCC // LTE // Ethernet // PE
Electromagnetic compatibility Conformance with RED Directive 2014/53/EU
Net weight 240 g
Housing material Plastic
Color gray
MTTF 383 Years (SN 29500 standard, temperature 25°C, operating cycle 21%)
184 Years (SN 29500 standard, temperature 40°C, operating cycle 34.25%)
78 Years (SN 29500 standard, temperature 40°C, operating cycle 100%)
Wireless licences Europe
Power supply
Supply voltage range 10 V DC ... 30 V DC (Via pluggable Push-in terminal block)
Max. current consumption 1.7 A
Typical current consumption < 200 mA (24 V DC)
65 mA (With activated energy-saving mode)
